Automatic ultrasionic surgical medical face mask making machine

  • METICA
  • MT-KZ-2
  • T/T
  • 30days Days
  • Shanghai, China

  • Aluminum alloy


Product Details



Automatic ultrasonic surgical medical face mask making machine production line

Feature:

  • 1.Adopting aluminum alloy rack which is more light and solider
  • 2. High stability
  • 3. One output line , high capacity
  • 4. Fully Automatically, save labor, just need one worker to operate
  • 5.Material in unwinding part use up, the machine can automatically stop .


Work process:
The machine includes a Mask main body making machine and two Automatic Mask Ear-loop welding machines Workflow as follows: 1.Materials feeding

2.Nose-bridge feeding

3.Nose-bridge cut insert

4.Pleating 5.Edge hemming 6.Ultrasonic welding 7.Cut to piece 8.Ear-loops welding (Ultrasonic)

    the Whole Machine technical parameter


    Application  3 ply surgical face mask making
    Production speed  100-120 pcs/min
    Power supply
     VAC220 50hz, 12kv
    Air supply  0.5-0.7mpa,  300L/min
    Ultrasonic
     20khz
    Machine size
     6500*4500*1900mm
    Weight
     <5000kgs


    Machine display:







    Project Examples





    On-site commissioning and installation
